| Thread Size | Ball Dia. | Overall Length | Stem Dia. | Effective Length | Order No. | Model |
|---|---|---|---|---|---|---|
M2 | 3.0 | 30 | 2.0 | 27.5 | 90030-30-30-2 | YK-A-5003-4177 |
| 4.0 | 2.5 | 30.0 | 90030-40-30-2 | YK-A-5003-1370 | ||
| 5.0 | 2.5 | 30.0 | 90030-50-30-2 | YK-A-5003-4779 | ||
| 6.0 | 2.5 | 30.0 | 90030-60-30-2 | YK-A-5003-4780 | ||
| 3.0 | 50 | 2.0 | 42.5 | 90030-30-50-2 | YK-A-5003-0064 | |
| 4.0 | 2.0 | 50.0 | 90030-40-50-2 | YK-A-5003-0065 | ||
| 5.0 | 2.5 | 50.0 | 90030-50-50-2 | YK-A-5003-0066 | ||
| 6.0 | 2.5 | 50.0 | 90030-60-50-2 | YK-A-5003-0470 |
