Length |
Stainless steel | Ceramic | Carbon fibre | |||
|---|---|---|---|---|---|---|
| Order No. | Model | Order No. | Model | Order No. | Model | |
| 5mm | 90090-10-05-5 | YK-M-5000-7634 | - | - | - | - |
| 10mm | 90090-10-10-2 | YK-M-5000-3647 | - | - | - | - |
| 20mm | 90090-10-20-2 | YK-M-5000-3648 | - | - | - | - |
| 30mm | 90090-10-30-2 | YK-M-5000-4162 | 90090-30-30-2 | YK-A-5003-0070 | - | - |
| 40mm | 90090-10-40-2 | YK-M-5000-7779 | 90090-30-40-2 | YK-A-5003-0071 | 90090-40-40-2 | YK-A-5003-2280 |
| 50mm | - | - | 90090-30-50-2 | YK-A-5003-0072 | 90090-40-50-2 | YK-A-5003-2281 |
| 70mm | - | - | - | - | 90090-40-70-2 | YK-A-5003-2282 |
| 90mm | - | - | - | - | 90090-40-90-2 | YK-A-5003-2283 |
| 100m | - | - | - | - | 90090-40-100-2 | YK-A-5003-2284 |
M3 Threaded Stylus Extensions
|
Length |
Stainless steel | Ceramic | Carbon fibre | |||
|---|---|---|---|---|---|---|
| Order No. | Model | Order No. | Model | Order No | Model | |
| 10mm | 90090-10-10-3 | YK-M-5000-7633 | - | - | - | - |
| 20mm | 90090-10-20-3 | YK-M-5000-3592 | - | - | - | - |
| 35mm | 90090-10-30-3 | YK-M-5222-3593 | - | - | - | - |
| 50mm | - | - | 90090-30-50-3 | YK-A-5003-0075 | 90090-40-50-3 | YK-A-5000-4864 |
| 70mm | - | - | - | - | 90090-40-70-3 | YK-A-5000-4865 |
M4 Threaded Stylus Extensions
|
Length |
Stainless steel | Ceramic | ||
|---|---|---|---|---|
| Order No. | Model | Order No. | Model | |
| 10mm | 90090-10-05-4 | YK-M-5000-7583 | - | - |
| 15mm | 90090-10-10-4 | YK-M-5000-7584 | - | - |
| 20mm | 90090-10-20-4 | YK-M-5000-7585 | - | - |
| 30mm | 90090-10-30-4 | YK-M-5000-7586 | 90090-30-30-4 | YK-A-5000-7754 |
| 50mm | - | - | 90090-30-40-4 | YK-A-5000-7755 |
| 100mm | 90090-30-50-4 | YK-A-5000-7727 | ||
M5 Threaded Stylus Extensions
|
Length |
Stainless steel | Carbon fibre A | Carbon fibre B | |||
|---|---|---|---|---|---|---|
| Order No. | Model | Order No. | Model | Order No. | Model | |
| 10mm | 90090-10-10-5 | YK-M-5555-0142 | - | - | - | - |
| 20mm | 90090-10-20-5 | YK-M-5555-0140 | - | - | - | - |
| 30mm | 90090-10-30-5 | YK-M-5555-0669 | - | - | - | - |
| 40mm | - | - | 90090-40-40-5A | YK-A-5555-0647 | 90090-40-40-5B | YK-A-5555-0620 |
| 50mm | 90090-10-50-5 | YK-M-5555-060 | 90090-40-50-5A | YK-A-5555-0648 | 90090-40-50-5B | YK-A-5555-0657 |
| 60mm | - | - | 90090-40-60-5A | YK-A-5555-0649 | 90090-40-60-5B | YK-A-5555-0658 |
| 70mm | - | - | 90090-40-70-5A | YK-A-5555-0623 | - | - |
| 80mm | - | - | 90090-40-80-5A | YK-A-5555-0650 | 90090-40-80-5B | YK-A-5555-0621 |
| 90mm | - | - | 90090-40-90-5A | YK-A-5555-0651 | - | - |
| 100mm | 90090-10-100-5 | YK-M-5555-0127 | 90090-40-100-5A | YK-A-5555-0652 | 90090-40-100-5B | YK-A-5555-0659 |
| 120mm | - | - | 90090-40-120-5A | YK-A-5555-0425 | 90090-40-120-5B | YK-A-5555-0660 |
| 150mm | - | - | 90090-40-150-5A | YK-A-5555-0424 | 90090-40-150-5B | YK-A-5555-0621 |
| 180mm | - | - | 90090-40-180-5A | YK-A-5555-0653 | 90090-40-180-5B | YK-A-5555-0662 |
| 200mm | - | - | 90090-40-200-5A | YK-A-5555-0654 | 90090-40-200-5B | YK-A-5555-0663 |
| 250mm | - | - | 90090-40-250-5A | YK-A-5555-0655 | 90090-40-250-5B | YK-A-5555-0427 |
| 300mm | - | - | 90090-40-300-5A | YK-A-5555-0642 | 90090-40-300-5B | YK-A-5555-0664 |
| 400mm | - | - | 90090-40-400-5A | YK-A-5555-0656 | 90090-40-400-5B | YK-A-5555-0665 |
| 500mm | - | - | - | - | 90090-40-500-5B | YK-A-5555-0667 |
| 600mm | - | - | - | - | 90090-40-600-5B | YK-A-5555-0668 |
