Thread Size | Ball Dia. | Overall Length | Stem Dia. | Effective Length | Order No. | Model |
---|---|---|---|---|---|---|
M5 | 6.0 | 50 | 4.0 | 39.0 | 90040-60-50-5 | YK-A-5003-5237 |
8.0 | 6.0 | 37.0 | 90040-80-50-5 | YK-A-5003-5238 | ||
10.0 | 6.0 | 37.0 | 90040-100-50-5 | YK-A-5003-5239 | ||
6.0 | 75 | 4.0 | 64.0 | 90040-60-75-5 | YK-A-5003-5250 | |
8.0 | 6.0 | 62.0 | 90040-80-75-5 | YK-A-5003-5251 | ||
10.0 | 6.0 | 62.0 | 90040-100-75-5 | YK-A-5003-5252 | ||
6.0 | 100 | 4.0 | 50.0 | 90040-60-100-5 | YK-A-5003-5259 | |
6.0 | 4.0 | 89.0 | 90040-60-100-5-B | YK-A-5003-5260 | ||
8.0 | 6.0 | 50.0 | 90040-80-100-5 | YK-A-5003-5261 | ||
8.0 | 6.0 | 87.0 | 90040-80-100-5-B | YK-A-5003-5262 | ||
10.0 | 6.0 | 50.0 | 90040-100-100-5 | YK-A-5003-5263 | ||
10.0 | 6.0 | 87.0 | 90040-100-100-5 | YK-A-5003-5264 |
Thread Size | Ball Dia. | Overall Length | Stem Dia. | Effective Length | Order No. | Model |
---|---|---|---|---|---|---|
M5 | 6.0 | 50 | 4.0 | 120.0 | 90040-60-150-5 | YK-A-5003-5265 |
8.0 | 6.0 | 120.0 | 90040-80-150-5 | YK-A-5003-5266 | ||
10.0 | 6.0 | 120.0 | 90040-100-150-5 | YK-A-5003-5267 | ||
6.0 | 200 | 4.0 | 180.0 | 90040-60-200-5 | YK-A-5003-5268 | |
8.0 | 6.0 | 180.0 | 90040-80-200-5 | YK-A-5003-5269 | ||
10.0 | 6.0 | 180.0 | 90040-100-200-5 | YK-A-5003-5270 | ||
6.0 | 300 | 4.0 | 280.0 | 90040-60-300-5 | YK-A-5003-5271 | |
8.0 | 6.0 | 280.0 | 90040-80-300-5 | YK-A-5003-5272 | ||
10.0 | 6.0 | 280.0 | 90040-100-300-5 | YK-A-5003-5273 |
